Aerion Helios 4.2MW Utility Wind Turbine

The Aerion Helios 4.2MW Utility Wind Turbine is engineered for grid-scale performance and quiet reliability. This three-bladed, white tower with high-visibility red tips leverages a permanent-magnet direct-drive generator, active pitch and yaw, and advanced SCADA for real-time control. Designed for utility wind farms and coastal installs, it delivers exceptional efficiency across variable wind regimes while maintaining low acoustic output and minimal maintenance requirements.

Specifications

• Tower & Blades: Tapered steel tower; glass-fiber/epoxy aerofoils with UV-safe red tips

• Rotor/Hub Height: 120 m rotor diameter / 110 m hub height

• Powertrain: 4.2 MW direct-drive PM generator, full-converter, IEC IIA

• Electrical: 690 V output, 50/60 Hz grid compliance

• Operating Range: Cut-in 3 m/s, rated 12 m/s, cut-out 25 m/s; survival 60 m/s

Features

• High-Efficiency Aerofoil Blades: Optimized for low turbulence and high annual energy

• Direct-Drive Generator: Fewer moving parts for ultra-low maintenance

• Active Pitch & Yaw: Intelligent control maximizes yield and protects components

• Low-Noise Operation: Serrated trailing edges and optimized tip geometry

• SCADA & Remote Monitoring: Real-time analytics, predictive maintenance alerts

• Climate-Ready Design: Lightning protection, anti-icing option, marine-grade coatings

Maintenance

• Daily: Remote SCADA health check and alarms review

• Weekly: Visual inspection of tower base, cables, and safety systems

• Annually: Full drivetrain inspection, blade NDT, lubrication, and firmware updates

Warranty

• Structural & Tower: 7 years

• Generator & Power Electronics: 3 years
